Hardware platform
Qualcomm IPQ5018 platform Wi-Fi 6 Model			Qualcomm IPQ53X2 platform Wi-Fi 7 Model
X5	X6	X5-NK	E5	E6	E516
X6-NK	X5-360	X521	E616	E519	E619
X519	X619	X520C	E520	E620	E520C
X620C	X523C	X623C	E620C	E523C	E623C
WIS-L525AX	WIS-D525AX	X621	E525C	E625C	M20
X4500	X4600	X4517C	E4518	E4618	E4517C
X4617C	X4518S	X4618S	E4617C	E4519S	E4619S
X4519S	X4619S	X4521C	E4521C	E4621C
X4621C	X516	X616
